The GPI G2S05T09QMA is a 1/2-inch turbine flow meter equipped with 3/4-inch Tri-Clamp® fittings, facilitating seamless integration into sanitary and industrial piping systems. Constructed with 316 stainless steel, it offers excellent chemical compatibility and durability, making it suitable for a wide range of fluids, including water, chemicals, and beverages. The meter operates within a flow range of 1 to 10 gallons per minute (GPM) and can withstand pressures up to 150 pounds per square inch (PSI). It features a digital LCD that displays flow rate, batch total, and cumulative total, ensuring precise monitoring and control. The device is factory-calibrated for water-like fluids but allows for field calibration to accommodate varying fluid types and conditions. Its modular design supports the addition of output modules, sensors, and remote transmitters, enhancing its versatility in diverse industrial settings.
Features:
- Flow range: 1 to 10 GPM (3.8 to 37.9 LPM)
- Pressure rating: Up to 150 PSI (10.2 Bar)
- Connection type: 3/4-inch Tri-Clamp® fittings
- Construction material: 316 stainless steel
- Digital LCD display showing flow rate, batch total, and cumulative total
- Factory-calibrated; field calibration available
- Modular design compatible with additional output modules and sensors
- Battery-powered with an approximate lifespan of 5 years
- Suitable for water-like fluids and compatible chemicals
