The Rosemount 752F1AI5 remote indicator operates on the FOUNDATION™ Fieldbus H1 segment, capable of displaying up to eight process variables such as pressure, flow, level, temperature, or valve position. These variables are displayed sequentially in three-second intervals, with configurable tags and engineering units for each. The device features an explosion-proof housing suitable for hazardous locations, ensuring durability and safety in challenging industrial environments. Additionally, it offers optional advanced function blocks, including PID, characterizer, arithmetic, and integrator, providing enhanced control capabilities.
Features:
- Display Capability: Up to eight process variables
- Communication Protocol: FOUNDATION™ Fieldbus
- Housing Material: Low-copper aluminum alloy or CF-8M (Cast 316 SST)
- Conduit Entry Sizes: ½–14 NPT, M20 × 1.5 (CM20), or JIS ½G
- Enclosure Rating: NEMA Type 4X, IP66, and IP68
- Optional Function Blocks: PID, characterizer, arithmetic, integrator
- Certifications: Explosion-proof, intrinsically safe, dust ignition-proof, suitable for hazardous locations
