PowerMaster MG-54 Industrial Hoist Operator

The PowerMaster MG-54 is engineered for demanding industrial environments, offering robust construction and dependable operation. Its primary speed reduction is achieved through an industrial gearbox with a bronze worm gear in an oil bath, ensuring smooth and durable performance. The high starting torque motor is designed for continuous duty and is protected from overload by a current sensing or thermal overload device. The operator includes a heavy-duty, full-voltage, across-the-line magnetic reversing contactor, which is mechanically and electrically interlocked. Electrical components are housed in a NEMA 1 enclosure integral to the operator, with a transformer provided to reduce control voltage to 24 VAC. The system is wired for an open/close/stop control station and features positive chain-driven rotary limit switches to control full open and close travel of the door. A floor-level manual disconnect chain is included for emergency release and manual operation, with an electrical interlock switch to disable the control circuit during manual operation.

Features:

• Motor: 1/2 HP, 460V, 3-phase, 60Hz, high starting torque, continuous duty industrial motor with overload protection.
• Speed Reduction: Industrial gearbox with bronze worm gear in an oil bath for primary reduction.
• Control System: Heavy-duty magnetic reversing contactor with mechanical and electrical interlocks; 24 VAC control voltage.
• Limit Switches: Positive chain-driven rotary type for precise door travel control.
• Manual Operation: Floor-level manual disconnect chain with electrical interlock for safe manual operation during power failure.
• Enclosure: NEMA 1 rated, housing all electrical components.
