The VFC404A-7W ring compressor features a direct-drive, 1.1 horsepower Totally Enclosed Fan Cooled (TEFC) motor, capable of operating on a wide range of voltages and frequencies. This design ensures efficient operation and adaptability to different power supplies. The compressor is constructed with robust materials, including aluminum impellers and housings, providing durability and longevity. It is UL recognized, CSA certified, and CE marked, meeting international safety and performance standards. The unit is designed for quiet operation and includes a pilot-duty thermal protector as standard equipment on all models.
Features:
- Motor Power: 1.1 HP
- Maximum Pressure: 54.5 inches H₂O
- Maximum Vacuum: 50 inches H₂O
- Maximum Airflow: 98 SCFM
- Voltage: 200-240/400-480V, 3-phase
- Frequency: 50/60 Hz
- Insulation Class: NEMA Class B
- Certifications: UL recognized, CSA certified, CE marked
- Construction: Aluminum impellers and housings
- Thermal Protection: Pilot-duty thermal protector included
- Noise Level: Designed for quiet operation
